270 mm(10.63 in) x 193 mm(7.60 in) x 38 mm(1.50 in)
Weight
NW: 1.20 kg (2.65 lb) GW: 3.00 kg (6.61 lb)
VCI Parameter
..
Processor
ARM 32-bit Cortex processor
Input Voltage
DC 8-30V
Operating Temperature
-30 to 70℃ （22-158℉），relative Humidity:<90%
Storage Temperature
-30 to 100℃（-22-212℉），relative Humidity:<90%
Communication model
Bluetooth or USB
Protocols
J1939, J1708, ISO 9141, ISO14230, ISO15765, ISO11898, SAE-J1850 VPW, SAE-1850 PWM, UDS, K/L lines, High speed CAN, Middle speed CAN, Low speed CAN and Single wire CAN
